MICRO IV™ Beacon Low Profile - Single Flash Strobe

  • An Envelope of Safety® product
  • The TOMAR MICRO IV™ strobe series is a rugged and reliable industrial signaling solution.
  • SKU:
  • Regular price MSRP:
  • YOUR PRICE:

PRODUCT OVERVIEW

The TOMAR MICRO IV™ strobe series is a rugged and reliable industrial signaling solution, designed for demanding environments and enhanced safety applications. An upgraded version of the proven MICROSTROBE, the MICRO IV operates across a wide input voltage range—12–80VDC or 16–24VAC—while maintaining consistent lamp brightness and flash frequency, thanks to its internally regulated power supply. This ensures dependable performance regardless of voltage fluctuations in the field. Engineered for durability, the power supply is fully potted in polyurethane to resist moisture, high voltage, and vibration, making it ideal for harsh industrial settings.

The MICRO IV’s construction further emphasizes longevity and serviceability. Housed in a tough, all-Lexan® enclosure with a field-replaceable plug-in lamp, it provides ease of maintenance without compromising performance. Each unit is polarity protected and equipped with built-in filters that guard against radio frequency interference and spike voltages. Backed by a 10-year warranty, the MICRO IV and its optional guard are UL component recognized for type E, EE, and ES electric industrial trucks, in compliance with UL standard #583, making it a trusted choice for safety-conscious operations.

MICRO IV™ Beacons - Model Numbers

  • Model No. 470SSGP–1280 - Description: DC strobe, wall plate mount - Voltage: 12 – 80VDC
  • Model No. 470S–1280 - Description: DC strobe, surface mount - Voltage: 12 – 80VDC
  • Model No. 470SMB–1280 - Description: DC strobe, magnetic mount and 6’ straight cord - Voltage: 12 – 80VDC
  • Model No. 470SMB–1280/CC - Description: DC strobe, magnetic mount and coil cord - Voltage: 12 – 80VDC
  • Model No. 490S–1280 - Description: DC strobe, 1/2” female pipe mount - Voltage: 12 – 80VDC
  • Model No. 492S–1280 - Description: DC strobe, 3/4” IPS slip mount - Voltage: 12 – 80VDC
    Note**- This product is NOT threaded.
  • Model No. 495S–1280 - Description: DC strobe, 1/2” male thread mount - Voltage: 12 – 80VDC

Key Features

  • Wide input voltage range
  • Universal mounting
  • Built-in RFI filters
  • 10,000 hour strobe lamp
  • Ten year warranty on power supply
  • One year warranty on lamp
  • Available in six lens colors
  • UL recognized (all models)
  • Lens has hermetic o-ring seal
  • NEMA 4X

Specifications

  • Flash Rate: 60 to 80 flashes per minute
  • Light Output: 50 effective candlepower (ECP)*
  • Voltage and Amperage:
    • 12-80VDC draws 0.4A average @ 12VDC tapering to 0.05A average @ 80VDC
    • 16-24VAC draws 0.35A average
  • Power Supply Output: 2.7 Watts 1.9 joules per flash. 190,000 Peak Candlepower**
  • Size and Weight: 5” tall x 3” dia. x 0.6 lbs ( 127mm x 76mm x 0.27kg )
  • Operating Temperature: -40°C to 65°C
  • Encapsulation: Fully potted in urethane material with no exposure to High Voltage possible

Architect and Engineer Specifications

The strobe light shall be TOMAR model number series 470, 480, 485, 490,492, 495 or approved equal. The light source shall be a plug-in field replaceable single-flash xenon strobe tube. The strobe light must have built-in RFI filters to protect against radio interference and spike voltages. It shall be polarity protected, and have a power supply fully potted in polyurethane. Voltage ranges shall be 12-80VDC or 16-24VAC, 120 VAC, and 240VAC. The strobe light shall be UL listed and of NEMA 4X type weatherproof design with screw-on Lexan® lens.

NOTES
*ECP (Effective Candlepower) is the intensity that would appear to an observer if the light were burning steadily.
**Peak Candlepower is the maximum light intensity generated by a flashing light during its light pulse.
